Ian Industries offers a wide range of 7075 T6 aluminum tent pole sizes and processing services
| Outer Diameter | 7mm, 7.9mm, 8.5mm, 9.0mm, 9.5mm, 11mm, 12mm,12.7mm, 13mm, 14mm, 15mm, 16mm, 19mm, 22mm or Customized |
|---|---|
| Length | Customized |
| Grade | 7075 Aluminum |
| Temper | T3-T9 |
| Surface Treatment | Anodizing, Powder Coating, Polishing |
| Color | Black, Red, Blue, Green, Gold, Purple or Customized |
| Product Standard | ASTM, ASME, EN, JIS, DIN, GB/T, etc |
| Processing Service | Pre-Bend, etc |
Tent pole material is aluminum 7005 T6. The main purpose of tent pole is to prop up the camping tent, It has good elasticity, high strength not easy to broken. Comparing with 7001 t6 material 7075 has better low temperature resistance. So it’s usually used for cold weather.
| Aluminum Tent Pole Size List | ||||||||||||||||||
| Outer Diameter | 7mm | 7.9mm | 8.5mm | 9.5mm | 11mm | 11mm | 11mm | 12mm | 12.7mm | 13mm | 13mm | 14mm | 15mm | 16mm | 16mm | 19mm | 19mm | 22mm |
| Wall thickness | 0.7mm | 0.7mm | 0.7mm | 0.7mm | 0.8mm | 0.9mm | 1mm | 0.9mm | 0.9mm | 0.8mm | 1mm | 1mm | 1mm | 1mm | 1.2mm | 1mm | 1.2mm | 1mm |
| Chemical Composition | |||||||||
| Grade | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | AL |
| 7071 | 0.35 | 0.4 | 1.6-2.6 | 0.2 | 2.6-3.4 | 0.18-0.35 | 6.80-8.0 | 0.2 | Balance |
| 7075 | 0.4 | 0.5 | 1.2-2.0 | 0.3 | 2.1-2.9 | 0.18-0.28 | 5.1-6.1 | 0.2 | Balance |
| Aluminum Tent Pole Mechanical Property | |||
| Grade | Tensile Strength (Mpa) | Yield strength (Mpa) | Elogation (%) |
| 7001 T6 | 648 | 576 | 10 |
| 7075 T5 | 560 | 495 | 7 |
